Product Overview
The Jazzy® Elite HD features two-motor, front-wheel drive technology and heavy-duty construction. The Jazzy Elite HD features
35.5 cm drive wheels for enhanced outdoor performance combined with a front-wheel drive design to provide tight turns for optimal indoor manoeuvrability in small spaces. Large front wheels add extra absorption for superb climbing capabilities and combine with front anti-tip wheels for handling various terrains with ease.
Features:
-
204.1 kg weight capacity
-
Up to 7.24 km/h maximum speed
-
60.9 cm turning radius
-
Up to 15.7 km per charge range
-
Comfortable, depth-adjustable, limited recline high-back seat with headrest
-
Easy rear access to batteries
-
Intuitive controller is easy to operate
-
Colour-through shroud
-
Angle-adjustable foot platform offers greater comfort
-
35.5 cm knobby tyres and optimum weight distribution provide superior traction
Specifications:
Weight Capacity 204 kg (450 lbs.)*
Maximum Speed Up to 6.4 km/h (4 mph)
Ground Clearance 7.6 cm (3”)
Turning Radius 61 cm (24”)
Overall Length 90.2 cm (35.5”)
Overall Width 61.6 cm (24.25”)
Drive Wheels 35.6 cm (14”) solid
Front Wheels 7.6 cm (3”) solid anti-tips
Rear Wheels 15.2 cm (6”) solid casters
Suspension Limited
Drivetrain Two-motor, front-wheel drive
Braking System Intelligent braking (electronic,
regenerative disc brakes)
Standard Electronics 60 amp,
Dynamic Shark controller
Battery Charger Off-board, 5 amp
Per-Charge Range Up to 15.77 km (9.8 miles)
Battery Requirements (2) 12 volt, deep cycle, NF-22
Battery Weight 17 kg (37 lbs.) each
Base Weight 44 kg (98.5 lbs.)
Standard Seat Weight 23 kg (51.5 lbs.) (high-back)
Standard Seat 51 x 46-51 cm (20” x 18-20”
